Typ	Hriadeľ - priemer d [mm]	Otvor – priemer D [mm]	Prenášaný M_K [Nm]	CAD
KLDB019	19	47	294
KLDB020	20	47	313	🗎 stp
KLDB022	22	47	362	🗎 stp
KLDB024	24	50	421
KLDB025	25	50	470	🗎 stp
KLDB028	28	55	578	🗎 stp
KLDB030	30	55	637	🗎 stp
KLDB032	32	60	784	🗎 stp
KLDB035	35	60	843	🗎 stp
KLDB038	38	65	1010	🗎 stp
KLDB040	40	65	1108	🗎 stp
KLDB042	42	75	1892	🗎 stp
KLDB045	45	75	1912	🗎 stp
KLDB048	48	80	2137	🗎 stp
KLDB050	50	80	2167	🗎 stp
KLDB055	55	85	2677	🗎 stp
KLDB060	60	90	2853	🗎 stp
KLDB065	65	95	3500	🗎 stp
KLDB070	70	110	5717	🗎 stp
KLDB075	75	115	6207	🗎 stp
KLDB080	80	120	6707	🗎 stp
KLDB085	85	125	8002	🗎 stp
KLDB090	90	130	8502	🗎 stp
KLDB095	95	135	10002	🗎 stp
KLDB100	100	145	13336	🗎 stp
KLDB110	110	155	14582	🗎 stp
KLDB120	120	165	19083	🗎 stp
KLDB130	130	180	20417
KLDB140	140	190	24920
KLDB150	150	200	30130
